Refrigeration

Modular ice maker, extrernal structure AISI 304 scotch brite, monoblock stainless steel frame, evaporator AISI 304, auger AISI 303 made. Granular ice. Low consumption (1 liter water / 1 kg ice). ON-OFF switch. Rotation sensor directly on evaporator. Dust proof water basin. Conformity to RoHS directive. Automatic water charge. Standard and special voltages. Model in Tropical Class +43°C. 1 m3 = 550 kg of ice. Usable bins: Bin PE530, Bin T250, Bin T420, Bin T830, Bin 1200DD, RB 140, RB 280, DRB 1100, DRB 2500. Working conditions: indoor location, ambient temperature - +10 - +43°C, water temperature - +3 - +32°C, voltage - -10% - +10%, water inlet pressure - 1-6 bar. Remote connection: 479.5-260 mm. Electrical connection: 67.5-290 mm. Refrigerant feeding pipe. Outlet pipe of gaseous refrigerant. Production in 24h: 510 kg. Refrigerant: R404A - R507 - R448A - R449A - R407F - R452A, capacity - 2.3 kW (evap. temp. -18°C).
