Pot washing machine Pro Flow, 264/204 GN 1/1 per hour
Model | 20722_GR_MAXI_PRO |
Power Type | Electrical |
Power | 21/29 kW (hot/cold) |
Temperature | +65/+85ºС (wash/rinse) |
Capacity | 165 l |
Dimensions | 1452/1842x1075/1682x2039(±25) mm |
Weight | 485 kg |
Water Outlet | Ø32 mm |
Voltage | 3~ 400-415 V/50 Hz |
Producer | Nordisk Clean Solutions |
Front-loaded pot washer with high capacity for large operations. Granule Maxi Pro is the largest model, with the highest hourly through-put, it handles a high volume of pots and pans as well as intense washing peaks with ease. High capacity: (max./normal) 264/204 GN 1/1 per hour. Wash with or without PowerGranules BIO®. Water-saving: saves on average 1,820 l per day and up to 540,000 l per year. Time-saving: clean wares in 2 min 40* sec. without pre-washing. Chemical-saving: saves on average 2.6 l per day - up to 780 l per year. Maximum output for production ranging from 800 to 4,000 hot meals a day. Steam reduction: Granule Maxi Pro is standard fitted with steam reduction, which serves for a better climate and working conditions and lowers the ventilation requirements in the pot wash area. 3 cycles, 2 modes: wash hygienically clean in minutes, using a minimum of natural resources! No pre-washing needed - just scrape and load, then choose cycle length and wash mode. HACCP wash log: the control system stores vital HACCP data for up to 200 wash cycles. The data log can be accessed via the control panel display or exported to a USB stick for further use or storage. Auto-reminders: the smart control system keeps track of the number of run wash cycles and reminds you when it's time to change wash water, granules, and to schedule your next preventive maintenance appointment. Technical details: wash programs with granules: ECO: 2 min 40 sec/ Short: 4 min 50 sec/ Normal: 6 min 50 sec. Wash programs without granules: ECO: 2 min 40 sec/ Short: 3 min 40 sec/ Normal: 5 min 40 sec. Capacity per program: 12 GN1/1 up to 65 mm depth or 8 GN1/1 up to 200 mm, 6 GN2/1 up to 65 mm depth or 4 GN2/1 up to 200 mm. Wash/rinse temp: 65/85°C. Granule Maxi Pro Flow Edition adds flexibility and makes your setup more ergonomic with 2 loose Pro cassettes, a trolley and wall-mounted hooks with wall protection, on which the cassettes can be hung. Including USB port for HACCP Log, GD Memo™, steam reduction unit and type AB air gap according to EN 1717. Standard equipment: 2 pcs 29364 Pro cassette, loads 12 x GN 1/1 or 6 x GN 2/1; 2 pcs 19313 divider for small GN containers, sizes 1/9-2/3; 1 pc 21838 scraper; 1 pc 22845 Cassette trolley + 1 pc 14565 Drip tray for trolley, 2 sets of 10694 Cassette hooks with wall protection, 2 pcs 11918 Granule collectors 8 litres, 16 litres PowerGranules® (in the machine). Enclosure rating IPX5.
*the savings calculations are based on a sample site preparing 1,500 hot meals per day and 300 operational days per year
